Universal Machining Centre 5Axis
Quantity |
1 |
Make |
DMG |
Name |
DMU 85 Mono Block |
Table Size |
850x750 |
X axis Travel |
935 |
Y axis Travel |
850 |
Z axis Travel |
650 |
Workpiece Weight |
1200 |
Accuracy |
0.008mm |
Rotation C axis |
360⁰ |
Swivel range A-axis |
120⁰/-120⁰ |
CNC Horizontal Turning Centre
Quantity |
1 |
Make |
DMG |
Name |
CTX-510 |
Chuck Size |
315mm |
Max Turning Ø |
460mm |
Turning length |
1050mm |
Tail Stock |
Yes |
Work piece Weight |
350Kg |
Accuracy |
0.01mm |
Quantity |
1 |
Make |
Mazak |
Name |
Quick Slant-30 |
Chuck Size |
200mm |
Max Turning Ø |
320mm |
Turning length |
1000mm |
Tail Stock |
Yes |
Work piece Weight |
200kg |
Accuracy |
0.03mm |
Quantity |
1 |
Make |
DMG Mori |
Name |
NLX-2000MC-500(Turn mill) |
Chuck Size |
200mm |
Max Turning Ø |
300mm |
Turning length |
500mm |
Tail Stock |
Yes |
Work piece Weight |
150Kg |
Accuracy |
0.01mm |
Quantity |
1 |
Make |
Ecoca |
Name |
MT-415MC -3000 |
Chuck Size |
400mm |
Max Turning Ø |
508mm |
Turning length |
2980mm |
Tail Stock |
Yes |
Work piece Weight |
2000kg / 350Kg |
Accuracy |
0.005mm |
CNC Vertical Turning Centre
Quantity |
1 |
Make |
Doosan |
Name |
PUMA V-550 |
Chuck Size |
315mm |
Max Turning Ø |
730mm |
Turning length |
750mm |
Tail Stock |
No |
Workpiece Weight |
500Kg |
Accuracy |
0.01mm |
CNC Vertical Machining Centre
Quantity |
1 |
Make |
DMG |
Name |
DMC 1035V |
TABLE SIZE |
1200x600mm |
X axis Travel |
1050mm |
Y axis Travel |
600mm |
Z axis Travel |
560mm |
Workpiece Weight |
1000Kg |
Accuracy |
0.01mm |
Quantity |
1 |
Make |
HMT |
Name |
VTC 800 |
TABLE SIZE |
600x600mm |
X axis Travel |
800mm |
Y axis Travel |
450mm |
Z axis Travel |
450mm |
Workpiece Weight |
800Kg |
Accuracy |
0.03mm |
Quantity |
1 |
Make |
DMG Mori |
Name |
NVX5100 |
TABLE SIZE |
1350x600mm |
X axis Travel |
1050mm |
Y axis Travel |
530mm |
Z axis Travel |
510mm |
Workpiece Weight |
1200Kg |
Accuracy |
0.002mm |
Conventional Vertical Turning Machine
Quantity |
1 |
Make |
Jungenthal |
Name |
VTL |
Chuck Size |
1600mm |
Max Turning Ø |
2000mm |
Turning length |
1000mm |
Tail Stock |
No |
Work piece Weight |
1500Kg |
Conventional Horizontal Boring Machine
Quantity |
1 |
Make |
TOS |
Name |
M100 A |
TABLE SIZE |
1000 X 1000 |
X axis Travel |
1300mm |
Y axis Travel |
1300mm |
Z axis Travel |
1000mm |
Workpiece Weight |
1000Kg |
Conventional Radial Drilling Machine
Quantity |
1 |
Make |
HMT |
Name |
RM-63 |
Metrology
Quantity |
1 |
Make |
Carl Zeiss |
Name |
Contura G2 |
TABLE SIZE |
1200 X 1000 |
X axis Travel |
1000mm |
Y axis Travel |
1200mm |
Z axis Travel |
600mm |
Software |
Calypso 2016,6.2 |
Accuracy |
1.8µ |
Quantity |
1 |
Make |
Faro |
Name |
Laser Line Probe |
TABLE SIZE |
9' Spherical |
Accuracy |
29µ - Faro Edge / 25µ - Laser |
